Turntable stretch wrapper epw135
- Mechanical engineering Made in Germany
- The epw135 allows wrapping of a wide range of packaged goods
- Automatic wrapping process with three possible wrapping programs (single wrapping, cross wrapping, splash protected)
- Internal film carriage, all moving parts in the tower
- Motorised pre-stretching system for film pre-stretching by 200 %, 250 % or 300 %
- Five program memory locations
- Door flap mechanism for even easier film roll changeover at an ergonomic height
- Flexible applications thanks to easy transport of the machine
- CE conformity
- Economical use of stretch wrap thanks to pre-stretching system
- Space saving and easy to transport
- Simple handling guarantees time savings
- Inexpensive acquisition costs, minimum setting and maintenance costs
- The epw135 is the robust film saving model in the epw100 range
- Digital panel with LEDs and real time display
- Selection of wrapping programs
- Adjustable speed for turntable, separate for upward and downward movements
- Adjustable speed for carriage, separate for upward and downward movements
- Electronically controlled smooth start-up and deceleration of the turntable with stop in home position
- Easily adjustable string system for wrapping reinforcement at the pallet base
- Precisely adjustable number of bottom, top and final wraps
- Infinitely adjustable film overlapping separately for upward and downward movements
- Film stretching at four different pallet positions for custom adjustment to the packaged goods
- Adjustable overlapping at the top
- Height scan by photocell
- Easy to understand symbols
- Indicator light for voltage supply
- Single wrapping program
- Cross wrapping program
- "Splash protection" program with stop for manual top sheet application
- Output range: up to max. 20 pallets per hour
- Connected load: 230 V AC, 50/60 Hz, single-phase
- Turntable diameter: 1650 mm
- Max. pallet dimensions: 1100 x 1200 mm
- Max. loading weight: 2000 kg
- Max. pallet height: 2400 mm
- Pre-stretching system: gear transmission
- Options:
- Ramp
- Base intake frame
- Manual top film dispenser
- Turntable enlargement
- Tower lengthening
- Photocell to detect black products
